Winslow Crater: A Not-So-Fresh, Fresh Crater
NASA/JPL/University of Arizona
Winslow Crater: A Not-So-Fresh, Fresh Crater
PSP_004313_1760  Science Theme: Impact Processes
twitter  •  facebook  •  tumblr

WALLPAPER
800
1024
1152
1280
1600
1920
2048



This fresh, approximately 1 kilometer diameter impact crater was targeted after examinations of temperature images derived from the Thermal Emission Imaging System (THEMIS). The brightness temperature image revealed that the crater is very distinctive, exhibiting a bright, warm ejecta blanket suggesting that it is “rockier” than the surrounding sands and dust of Syrtis Major.

This caption describes two images that form a stereo-pair, that is often useful to study the same area at different times and to note any differences for further examination. This animated image demonstrates the principle of having a stereo-pair.

In the first HiRISE image of Winslow Crater (PSP_004313_1760), distinct dark rays surrounding the crater and are consistent with the THEMIS data’s suggestion of rockier materials. V-shaped patterns in the rays — referred to as a “herringbone” pattern — are identical to those around fresh lunar craters. These form when materials are ejected from the crater at a very low angle, which form clusters of secondary craters that preferentially eject materials down-range in a V-shaped pattern. (It‘s the same pattern that you would get when shooting a water pistol nearly parallel to a sidewalk.)

Also noteworthy are the large meter-to-decimeter-sized boulders on the steep rim that have not been buried or physically weathered to smaller sizes in this windy region, indicating that they have not been exposed long. This is also reminiscent of Meteor Crater and examples of fresh simple craters on the Moon.

The ring of rocky, cliff-forming materials in the inner wall of the crater represents original bedrock that was uplifted and exposed by the impact. The characteristic morphology is called “spur and gully” consisting of both the protruding bedrock inter-fingered with debris shoots feeding fans of sandy materials that extend down to the crater floor. Throughout this region, the present-day surface consists of a mix of global dust and volcanic sands from the Syrtis Major complex that typically cover the local bedrock. Winslow Crater is an excellent example of how craters can provide a window into the subsurface by exposing the local bedrock within the ejecta and crater wall.

Second Image
Later, a second HiRISE image of Winslow ( PSP_005658_1760) was taken to obtain a stereo-pair useful for determining the relief and topography of the crater and its surroundings. By chance this second image was taken after the dust storm that enveloped the planet in June 2007. Dust deposited during this storm blanketed the region and largely obscured the brightness differences between the dark rays and the surrounding bright soil. Laboratory experiments on natural surfaces indicate that a layer of dust only a few tens of microns thick is sufficient to achieve such obscuration. The thin dark lines that cross the later image show that dust-devils have already begun the work of cleansing the surface of dust and restoring the region to its previous appearance.

Naming the Crater
Due to its similar size and remote thermal infrared (TIR) characteristics similar to Meteor Crater, Arizona, the name Winslow Crater was suggested after the small town roughly 20 km to the east of Meteor Crater, and the International Astronomical Union’s committee on Planetary Nomenclature agreed. (For further information on Planetary Nomenclature click here).Written by: Livio L. Tornabene, Paul Geissler and Shawn Wright  (9 January 2008)

This is a stereo pair with ESP_012356_1760.

Acquisition date
28 June 2007

Local Mars time:
14:56

Latitude (centered)
-3.742°

Longitude (East)
59.167°

Spacecraft altitude
263.7 km (164.8 miles)

Original image scale range
26.4 cm/pixel (with 1 x 1 binning) so objects ~79 cm across are resolved

Map projected scale
25 cm/pixel and North is up

Map projection
Equirectangular

Emission angle:
5.8°

Phase angle:
42.2°

Solar incidence angle
47°, with the Sun about 43° above the horizon

Solar longitude
266.3°, Northern Autumn

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  334.2°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (693MB)

IRB color
map-projected   (345MB)

JP2 EXTRAS
Black and white
map-projected  (293MB)
non-map           (421MB)

IRB color
map projected  (101MB)
non-map           (305MB)

Merged IRB
map projected  (181MB)

Merged RGB
map-projected  (174MB)

RGB color
non map           (302MB)
ANAGLYPHS
Map-projected, reduced-resolution
Full resolution JP2 download
Anaglyph details page

ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
