Degradation of Craters in Noachis Terra
NASA/JPL/UArizona
Degradation of Craters in Noachis Terra
ESP_062388_1450  Science Theme: Composition and Photometry
Small impact craters usually have simple bowl shapes, but in some cases surface properties or processes can alter this shape in unusual ways.

This image shows an approximately 300-meter impact crater that appears to have narrow terraces around the rim. How could these different crater morphologies form? One explanation is that the impact occurred into a surface with layers of differing strengths. However, the clearest example of this type of crater are better-preserved than this one.

Additional clues come from other craters that have a raised mound in the center as opposed to a depression and are sometimes referred to as inverted craters due to their topography. These craters were filled with sediment (or some material stronger than the surrounding material), and subsequent erosion removed the terrain around the filled material, leaving a small mound behind.

Written by: Eric Pilles, Will Yingling, and Livio L. Tornabene  (3 February 2020)

Acquisition date
17 November 2019

Local Mars time
15:30

Latitude (centered)
-34.822°

Longitude (East)
3.629°

Spacecraft altitude
255.3 km (158.7 miles)

Original image scale range
51.7 cm/pixel (with 2 x 2 binning) so objects ~155 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle
9.0°

Phase angle
71.4°

Solar incidence angle
77°, with the Sun about 13° above the horizon

Solar longitude
108.2°, Northern Summer

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  49.0°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (159MB)

IRB color
map-projected   (98MB)

JP2 EXTRAS
Black and white
map-projected  (69MB)
non-map           (95MB)

IRB color
map projected  (26MB)
non-map           (75MB)

Merged IRB
map projected  (153MB)

Merged RGB
map-projected  (147MB)

RGB color
non map           (73MB)
ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images

USAGE POLICY
All of the images produced by HiRISE and accessible on this site are within the public domain: there are no restrictions on their usage by anyone in the public, including news or science organizations. We do ask for a credit line where possible:
NASA/JPL/University of Arizona

POSTSCRIPT
NASA’s Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, Calif., manages the Mars Reconnaissance Orbiter for NASA’s Science Mission Directorate, Washington. The HiRISE camera was built by Ball Aerospace and Technology Corporation and is operated by the University of Arizona.
