A Slice of Polar Layer Cake
NASA/JPL/UArizona
A Slice of Polar Layer Cake
ESP_062216_2660  Science Theme: Polar Geology
The Martian ice cap is like a cake with every layer telling a story. In this case, the story is one of climate change on Mars.

In this image is an exposed section of the north polar layered deposits (NPLD). Like a delicious slice of layered tiramisu, the NPLD is made up of water-ice and dust particles stacked one on top of the other. However, instead of icing, layers are topped with seasonal carbon dioxide frost. We can observe lingering frost adhering to one of the layers.

The high-resolution and color capabilities of HiRISE provide details on the variations in the layers. Scientists are also using radar data, which show us that they have continuity in the subsurface. During deposition, these complex layers might encapsulate tiny air pockets from the atmosphere which, if sampled, could be studied to understand linkages to previous climates.

In the end, it’s not always a piece of cake studying NPLD on Mars but, where there is cake, there is hope!

Written by: Chimira Andres, Livio Leonardo Tornabene, Leah Sacks, and Vidhya Ganesh Rangarajan  (14 February 2020)

Acquisition date
04 November 2019

Local Mars time
12:33

Latitude (centered)
85.984°

Longitude (East)
327.104°

Spacecraft altitude
318.8 km (198.2 miles)

Original image scale range
31.9 cm/pixel (with 1 x 1 binning) so objects ~96 cm across are resolved

Map projected scale
25 cm/pixel

Map projection
Polarstereographic

Emission angle
0.6°

Phase angle
61.0°

Solar incidence angle
61°, with the Sun about 29° above the horizon

Solar longitude
102.2°, Northern Summer

For non-map projected images
North azimuth:  132°
Sub-solar azimuth:  318.7°
