Polygonal Patterns Highlighted by Frost
NASA/JPL/University of Arizona
Polygonal Patterns Highlighted by Frost
ESP_060685_2480  Science Theme: Composition and Photometry
twitter  •  tumblr

HICLIP
1080p (MP4)
Audio (MP3)

WALLPAPER
800
1024
1152
1280
1440
1600
1920
2048
2560
2736
2880
3072
4500
4K
8K
10K

HIFLYER
PDF (11 x 17)

HISLIDES
PowerPoint
Keynote
PDF

It’s spring in the Northern Hemisphere of Mars (when this image was taken), and this area was recently completely covered by the seasonal frost cap. Here, we see polygonal patterns that are highlighted by carbon dioxide frost that has not entirely sublimed away.

These organized patterns are likely caused by differences in the soil (regolith) characteristics such as grain size, density, even grain-shape and orientation in the underlying landforms and geologic materials. Variations in these characteristics strongly influence the strength of the ice-rich permafrost. This gives a preferred orientation to the stress field that produces the polygonal patterns.

In this case, there appears to have been a meander in a fluvial channel in which sediments that differ from the native soil were deposited. The physical properties of these sediments probably change near the channel banks where flow rate drops off. Additionally, a high ice content might have resulted from a sediment-rich slurry flow that froze in place. Higher ice content will produce a weaker stress field and larger polygons, more so than just changes in grain size or orientation.

Written by: Ken Herkenhoff and Mike Mellon (narration: Tre Gibbs)  (18 November 2019)

Acquisition date
08 July 2019

Local Mars time
14:21

Latitude (centered)
67.892°

Longitude (East)
36.305°

Spacecraft altitude
313.7 km (195.0 miles)

Original image scale range
62.8 cm/pixel (with 2 x 2 binning) so objects ~188 cm across are resolved

Map projected scale
50 cm/pixel

Map projection
Polarstereographic

Emission angle
2.0°

Phase angle
55.5°

Solar incidence angle
54°, with the Sun about 36° above the horizon

Solar longitude
49.7°, Northern Spring

For non-map projected images
North azimuth:  99°
Sub-solar azimuth:  321.3°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (217MB)

IRB color
map-projected   (113MB)

JP2 EXTRAS
Black and white
map-projected  (123MB)
non-map           (85MB)

IRB color
map projected  (62MB)
non-map           (88MB)

Merged IRB
map projected  (219MB)

Merged RGB
map-projected  (195MB)

RGB color
non map           (77MB)
ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
