Araneiform terrain (colloquially: spider-like terrain) is located in the south polar region of Mars and evolves in appearance over the spring and summer. In the season shown here, the thin bright lines on the surface (the spider legs) are troughs and many of these features have dark fan-shaped markings emanating from them.

Our current theory for how these patterns are formed is that during winter a carbon dioxide ice layer develops over the surface. When sun rays strike this surface, this carbon dioxide ice acts in a similar way to our atmosphere: it allows the sun light to penetrate but traps the infrared radiation creating a greenhouse-like effect.

The trapped heat transforms the ice at the bottom of the layer to gas, building up pressure until it bursts through. When that happens, the gas flows out in geyser-like fashion and carries dust with it, which falls back to the surface to form the dark fans.

Written by: M. Ramy El-Maarry  (10 December 2018)

Acquisition date
18 September 2018

Local Mars time
17:31

Latitude (centered)
-85.733°

Longitude (East)
83.646°

Spacecraft altitude
245.7 km (152.7 miles)

Original image scale range
24.6 cm/pixel (with 1 x 1 binning) so objects ~74 cm across are resolved

Map projected scale
25 cm/pixel

Map projection
Polarstereographic

Emission angle
0.0°

Phase angle
65.6°

Solar incidence angle
66°, with the Sun about 24° above the horizon

Solar longitude
252.2°, Northern Autumn

For non-map projected images
North azimuth:  128°
Sub-solar azimuth:  43.1°
