This is Not the Hydrothermal Deposit You’re Looking For
NASA/JPL/University of Arizona
This is Not the Hydrothermal Deposit You’re Looking For
ESP_055282_2125  Science Theme: Hydrothermal Processes
twitter  •  facebook  •  tumblr

HICLIP
1080p (MP4)
Audio (MP3)

WALLPAPER
800
1024
1152
1280
1440
1600
1920
2048
2560
2736
2880
4500
4K
8K
10K

HIFLYER
PDF (11 x 17)

HISLIDES
PowerPoint
Keynote
PDF

A hotspot for exploration on Mars centers on areas that were once, or are currently, next to a significant source of heat such as volcanoes. Martian volcanoes have not been active for the last couple million years, but beneath the shifting sands and dust of the Red Planet we find old lava flows frozen in time.

These ancient lava flows may have provided a source of heat, along with liquid water or subsurface ice, to generate an environment conducive for the development of ancient life. Geological evidence for hot water interacting with rock is what we mean by hydrothermal: sites with these conditions are very difficult to identify from orbit.

One closeup view shows sand dunes scouring what appears to be a highly-cratered, old lava flow in the Tempe Terra region, located in the Northern Hemisphere. The flat, dark areas are basaltic in composition, a rock commonly found around active volcanoes, and the lighter-toned material is covered in rusted Martian dust. The recently-launched InSight lander will reveal whether Mars is geologically active internally.

Written by: Sarah Simpson, Alyssa Werynski, Jennifer Newman, Eric Pilles, Livio Tornabene (audio: Tre Gibbs)  (23 July 2018)

Acquisition date
13 May 2018

Local Mars time:
15:22

Latitude (centered)
32.116°

Longitude (East)
294.906°

Spacecraft altitude
288.9 km (180.5 miles)

Original image scale range
57.8 cm/pixel (with 2 x 2 binning) so objects ~173 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle:
0.3°

Phase angle:
56.3°

Solar incidence angle
56°, with the Sun about 34° above the horizon

Solar longitude
174.7°, Northern Summer

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  344.7°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (335MB)

IRB color
map-projected   (192MB)

JP2 EXTRAS
Black and white
map-projected  (161MB)
non-map           (177MB)

IRB color
map projected  (74MB)
non-map           (160MB)

Merged IRB
map projected  (339MB)

Merged RGB
map-projected  (316MB)

RGB color
non map           (152MB)
ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images

USAGE POLICY
All of the images produced by HiRISE and accessible on this site are within the public domain: there are no restrictions on their usage by anyone in the public, including news or science organizations. We do ask for a credit line where possible:
NASA/JPL/University of Arizona

POSTSCRIPT
NASA’s Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, Calif., manages the Mars Reconnaissance Orbiter for NASA’s Science Mission Directorate, Washington. The HiRISE camera was built by Ball Aerospace and Technology Corporation and is operated by the University of Arizona.
