Barchan Pac-Man
NASA/JPL/University of Arizona
Barchan Pac-Man
ESP_054515_1930  Science Theme: Aeolian Processes
twitter  •  facebook  •  google+  •  tumblr

HICLIP
1080p (MP4)
Audio (MP3)

WALLPAPER
800
1024
1152
1280
1440
1600
1920
2048
2560
2736
2880
4500
4K
8K
10K

HIFLYER
PDF (11 x 17)

HISLIDES
PowerPoint
Keynote
PDF

Barchan sand dunes are common on Mars and often form vast dune fields within very large (tens to hundreds of kilometers) impact basins. The regions upwind of barchans are usually devoid of sandy bedforms, so if you were walking in a downwind direction, then the barchans would seem to appear out of nowhere.

As you walk downwind, you would notice the barchans link up (“joining arms”) and eventually slope into featureless sand sheets. We call this progression of dunes a “Herschel-type dune field” named after the first place this sequence was described: Herschel Crater.

But here is something interesting: a barchan dune filling the upwind portion of a small impact crater in a Pac-Man-like shape. This “dune-in-a-crater” is nearly at the highest extent of the field. It’s also probably a rare configuration, and over the next few tens of thousands of years the sand will be blown out of the crater. Enjoy it while it lasts!

Written by: Kirby Runyon (audio: Tre Gibbs)  (14 May 2018)

Acquisition date
14 March 2018

Local Mars time:
15:19

Latitude (centered)
12.884°

Longitude (East)
356.280°

Spacecraft altitude
279.5 km (174.7 miles)

Original image scale range
55.9 cm/pixel (with 2 x 2 binning) so objects ~168 cm across are resolved

Map projected scale
50 cm/pixel and North is up

Map projection
Equirectangular

Emission angle:
0.2°

Phase angle:
48.3°

Solar incidence angle
48°, with the Sun about 42° above the horizon

Solar longitude
143.2°, Northern Summer

For non-map projected images
North azimuth:  97°
Sub-solar azimuth:  14.6°
JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (303MB)

IRB color
map-projected   (177MB)

JP2 EXTRAS
Black and white
map-projected  (163MB)
non-map           (149MB)

IRB color
map projected  (64MB)
non-map           (164MB)

Merged IRB
map projected  (295MB)

Merged RGB
map-projected  (275MB)

RGB color
non map           (159MB)
ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images
