HiRISE | Northern Ladon Basin (ESP_026205

NASA/JPL-Caltech/UArizona

Northern Ladon Basin
ESP_026205_1635 Science Theme:

This image reveals the surface along the northern margin of Ladon Basin, near where deposits partially filling the basin meet with surrounding highlands materials.

A number of valleys terminate around the Ladon Basin margin, which is also punctuated by Ladon Valles and Morava Valles. Most of these drainages source the basin, whereas Morava drains it. Because Ladon basin lies along a larger drainage extending well to the south and into the Argyre region, sediments partially filling the basin may record a long and complicated history of infilling.

The basin once may have held a lake, though this remains uncertain. Study of the brighter sediments within the basin and visible in portions of the image may provide clues to the amount and process of infilling and help resolve this question.

Written by: John Grant (26 April 2012)

Acquisition date
28 February 2012

Local Mars time
15:19

Latitude (centered)
-16.291°

Longitude (East)
330.260°

Spacecraft altitude
262.9 km (163.4 miles)

Original image scale range
29.3 cm/pixel (with 1 x 1 binning) so objects ~88 cm across are resolved

Map projected scale
25 cm/pixel and North is up

Map projection
Equirectangular

Emission angle
27.1°

Phase angle
47.3°

Solar incidence angle
63°, with the Sun about 27° above the horizon

Solar longitude
76.5°, Northern Spring

For non-map projected images
North azimuth: 97°
Sub-solar azimuth: 48.2°

JPEG
Black and white
map projected  non-map

IRB color
map projected  non-map

Merged IRB
map projected

Merged RGB
map projected

RGB color
non-map projected

JP2
Black and white
map-projected   (1328MB)

IRB color
map-projected   (920MB)

JP2 EXTRAS
Black and white
map-projected (746MB)
non-map           (589MB)

IRB color
map projected (339MB)
non-map           (563MB)

Merged IRB
map projected (379MB)

Merged RGB
map-projected (360MB)

RGB color
non map           (571MB)

ADDITIONAL INFORMATION
B&W label
Color label
Merged IRB label
Merged RGB label
EDR products
HiView

NB
IRB: infrared-red-blue
RGB: red-green-blue
About color products (PDF)

Black & white is 5 km across; enhanced color about 1 km
For scale, use JPEG/JP2 black & white map-projected images

USAGE POLICY
All of the images produced by HiRISE and accessible on this site are within the public domain: there are no restrictions on their usage by anyone in the public, including news or science organizations. We do ask for a credit line where possible:
NASA/JPL-Caltech/UArizona

POSTSCRIPT
NASA’s Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, Calif., manages the Mars Reconnaissance Orbiter for NASA’s Science Mission Directorate, Washington. The HiRISE camera was built by Ball Aerospace and Technology Corporation and is operated by the University of Arizona.
